GTAW (TIG) WELDING RODS FOR TOOL & DIE REPAIR, MAINTENANCE -HARDFACING

Gas tungsten arc welding (GTAW), also known as tungsten inert gas (TIG)
welding, is an arc welding process that uses a nonconsumable tungsten
electrode to produce the weld. GTAW is most commonly used to weld thin
sections (<10 mm) of stainless,steel ,nickel, monel titanium, aluminium,
magnesium and copper alloys. It is also the ideal process for repair and build
up on tools and dies. The process grants the operator greater control over the
weld than competing processes such as shielded metal arc (SMAW) and gas
metal arc welding GMAW) , allowing for stronger, higher quality welds.

Get A Quote View Pdf
PRODUCT CODE

GOLD

DESCRIPTIONS/ APPLICATION  TECHNICAL

DETAILS

SIZE

Ø

mm

330 T  Multipurpose high strength TIG (GTAW) filler wire for  welding alloy and high-alloy-steels, cold working tool-steels,  stainless steels, difficult to weld and dissimilar steel welding.  (SKD11,SKD61) Use for buffer layer before hard facing .  Weld SUS 304,SUS 420 , repair shafts, piston rods etc. CLASSIIFICATION : ISO 14343 A W 29 9 Tensile strength: 730 Rm (MPa)

Hardness as welded  HB 200-210

Work hardens to  HB 400-450

1.6

2.4

420 T  High strength Fe Ni Alloy for welding on cast iron and  joining cast iron to steel. For repairs on glass and press  molds ,engine and cylinder blocks ….. Hardness:

130-160 HB

Material 2.4560

2.4
728 T  For repairs and overlays on Aluminium-die casting and  plastic injection moulds ,cold and hot working dies  (SKD11,H13 ) Boehler K110Stavax ESR . For welding  maraging steel 200-500,Deposit can be machined and age  hardened at 480 C to 50 HRC Hardness:

HRC 34-36

as welded

Material No.

~1.6356

1.0

1.6

2.5

1015 T  For tool and die repair. Deposits are machinable. High  impact resistance and toughness. Use for trimming tools,  hot and cold cutting dies shear blades, etc.  Hardness

(HRC) 41-46

Mat. No. 1.2567

1.6

2.4

7201 T  For repair and build ups on tools and dies subject to  high impact and medium abrasion.

Can be used for overlays on case and air hardening steels, Nitriding steels(1.8519,1.8521,1855) and cast iron Excellent cutting ability.

Hardness:

HRC58-60

Mat. No.1.4718

Alloy: Fe, Cr Si.Ni C

1.6

2.4

1045 T

(Co 6)

Cobalt based Rod for surfacing of parts which are subjected  to a combination of metal/metal wear, corrosion and heat up  to 650 °C and shortly up to 1000°C.Especially for rebuilding

edges of Valve seats, cutting tools , knives, shear blades,  drills, punching dies, press etc.Excellent hot hardness.

Hardness:

39-43HRC

Co Cr,W,Ni,Fe,

WSG-20-GO-40CTZ

3.2
1047 T

(Co 12)

Cobalt base rods with high impact resistance specially de velop for hardfacing of hot working and wood cutting tools. Alloy: Ni, Cr, Mo, Co, WC, Fe Hardness:

HRC 34 at 400°EN 14700 S Co2

3.2
1049 T

(Co 21)

High cobalt and chrome alloy. For building up engine valve  and valve seats , gas turbines, furnace parts, heat treating  baskets, cams , hot trimming ,drop forging hammers & dies,

mixers for chemical processing, extrusion nozzles, press  tools.

Hardness:

28-34 HRC

~ 20 HRC at 400°AWS A5.21

ERCoCr-E

3.2
