ALUMINIUM- WELDING -BRAZING-OVERLAYING
Aluminum is a unique and widely used non ferrous metal
It is light weight, strong ,has a good corrosion resistance and a good
conductor of heat and electricity .
Aluminum is used extensively in the following industries.
- Transportation: Automobile, aircraft, trucks, railways, cars,
marine vessels, bicycles etc. - Construction of windows, doors, street lighƟng post, masts
- Air-condition, refrigeration
- Electrical transmission lines ,bus bars etc.
Aluminum can be joined by welding processes such as
- TIG (GTAW) MIG (GMAW) or MMA and by Brazing or soldering
- The choice of process will depend on size of part, availability of equipment and strength of joint required.
FILLER METALS. WELDING-BRAZING
We supply aluminum alloy filler metals in different alloys and sizes ,in
rod or spool form .
FILLER METALS FOR BRAZING.
We offer a wide range of aluminum filler rods and fluxes for general flame induction or furnace brazing application.
ALUMINIUM– FILLER METALS– PRODUCT RANGE
| Filler Metal Code | AWS A 5.10 Class.
DIN 1732 Standard Alloy |
Form of delivery | Features
Application |
| 610 T / M | ER 4047 ALSI12 3.2585 | Rods (T) Spools (M) | For flame and furnace brazing of aluminum alloys, thin flowing ,smooth uniform fillets. (use with flux 40 PA /40 Fl or 40 FL/N
For TIG or MIG welding of Al Si Alloys. |
| 612 T/M | ER 4043
ALSI 5 3.2245 |
Rods (T) Spools (M) | Welding of Al alloys wit Si content of up to 7 %.,suitable for wide range of AL alloys.
Alloy 3004 ; 3005 ; 3303 ; 5005 ; 6060 ; 6061 ; 6071 ; 6063 Can also be used for brazing of aluminum |
| 611 T /M | ER1100 AL 99.5 | Rods (T) Spools (M) | Welding of pure aluminum such as AL 99.5,Al 99.7,AL99 Alloy 1080 A ; 1050 A ;1100 ; 3004 ; 3005, 3303 |
| 615 T/M | ER 5356
Al Mg 5 3.3565 |
Rods (T) Spools (M) | Solid wire for welding of AL Mg Alloys Such as alloy 5056,5083,5086,5454,5754
Used extensively in marine and transport. |
| 40 PA
40 PA/NC |
PA (corrosive flux residues)
PA/NC (non corrosive residues) |
Paste 1 kg | Paste type flux for brazing most types of Al ,
Used with rods such as gold 610 T,ER 4047 |
| 40 FL
40 FL/NC |
FL (corrosive flux residues)
FL/NC (non corrosive – residues) |
Powder
0.5 kg/1 kg |
Powder flux for brazing most types of Al ,
Used with rods such as 610 T,ER 4047 |
| Legend: T : Rods for GTAW (TIG) Welding are supplied in diam. 1.6,2.0, 2.4 and 3.2 mm / lengths of 1 m Packing : 5/ 10 kg Cardboard Boxes .
M : Wire for GMAW (MIG ) Welding supplied on spools BS 300 weight 7 kg .Other spools on request |
|||
| Disclaimer: The information and data presented herein are typical or average values. Application suggested are made solely for the purpose of illustration to enable the reader to make his own valuation and are not intended as warrantieswww. arcwel.com update August . 2022 |
|||
